AZY-FC610.5 ANZHIYA 0.5kVA AC Power Supply 50hz 60hz Single Phase 40hz-499.9hz Stabilized Voltage and Frequency Converter

Specification：

①　Input Phase : Single Phase

②　Input voltage: 480VAC±10%

③　Output Phase: Single  Phases

④　Output voltage: 0-520VAC Continuously adjustable

⑤　Voltage accuracy: ≤±1%

⑥　Output frequency: 50hz

⑦　Frequency adjustment resolution: 0.1Hz

⑧　Low Grade(Each phase) Output current：4.2A

⑨　High Grade(Each phase)Output current：2.1A

⑩　Output capacity:0.5KVA，0.4KW

⑪　Circuit mode: IGBT/SPWM

⑫　Machine size:430*180*440MM

⑬    NW: 26KG



We specialize in customizing AC/DC/AC power supply to meet your specific requirements.

With customized any kind frequency converters, our offerings range up op to 2000KVA.

Please visit our website and submit any inquiries to explore our capabilities further. Our dedicated team endeavors to respond within one hour.

Thank you for considering our services.
