Three-phase inverter power supply is a high-performance precision power supply equipment, which is capable of transforming the existing AC grid current into a stable and pure sine wave power supply of the required frequency.
This kind of power supply equipment is widely used in home appliance manufacturing, motor, electronic manufacturing, IT industry, computer equipment manufacturing, laboratory and test units, aviation, military units, medical equipment, railroads, oil drilling platforms and other fields, for the provision of different electric power and special requirements of the place required power.
I.Working Principle
The working principle of three-phase inverter power supply is to convert the input three-phase AC power supply into DC power through rectifier circuit, then smooth the fluctuation of DC power through filter circuit, and finally convert DC power into high frequency AC power through inverter circuit.
The inverter circuit is the core part to control the frequency and voltage, which is usually realized by using modulation techniques such as SPWM (Sinusoidal Pulse Width Modulation) or MPWM (Modulated Pulse Width Modulation Technique).
Ultimately, the voltage is raised or lowered by a transformer to output a three-phase AC power supply with adjustable frequency and voltage.
II.Main features
1.High efficiency and energy saving: The three-phase inverter power supply can automatically adjust the output power according to the needs of the load, realizing high efficiency and energy saving.
2.Precise control: It can accurately output ≤1% of voltage and ≤0.01% of frequency to meet different application requirements.
3.High reliability: Adopting advanced power electronic technology and control algorithm, it has high reliability and stability.
4.Low maintenance cost: Due to the use of advanced electronic components and control technology, the maintenance cost is relatively low.
5.Wide range of applications: Widely used in industrial automation, mechanical equipment, ships, wind power generation, motor speed control, lighting equipment, communication equipment, induction cookers, welding machines, medical equipment and other fields.
III.Protective function
Three-phase inverter power supply is usually equipped with multiple protection functions, such as over-voltage, over-current, over-temperature and other protection and alarm devices, to ensure that the power supply can operate safely and stably under abnormal conditions.
Anzhiya Three-phase inverter power supply has a wide range of output power, ranging from 10kVA for single-phase to 2000kVA for three-phase, the output voltage range can be from 0-155V (low grade) to 0-310V (high grade), and the output frequency can be from 45Hz to 65Hz and even higher frequency output (such as 100Hz/120Hz/200Hz/240Hz/400Hz, optional). ).
Input voltage: 3 phase 4 wire 380/220 VAC 60 Hz
Output voltage: 3 phase 4 wire 115 VAC Standard ) 400 Hz
Output Voltage :Low Range 0-260VAC
Output Voltage : High Range 0-520VAC
Voltage accuracy: ≤±1%
Output frequency: 400HZ ( fixed)
Frequency adjustment resolution: /
Low Grade(Each phase) Output current:208.4A
High Grade(Each phase)Output current:104.2A
Output capacity: 75KVA,60KW
Circuit mode: IGBT/PWM
Machine size: 1000*800*1800(MM)
NW:380KG ,GW:450KG
